RELAY:Smartstart Chrging BCDC1250D LiPo
RELAY:Smartstart Chrging BCDC1250D LiPo

BCDC1250D

$620.00

Under Bonnet 12V 50A DC to DC Battery Charger

Currently out of stock in store. Contact us to order this product.

SKU: 9338628004690 Categories: , Tag:

Description

Western Australia – Flooded Outback gravel road with 4WD car crossing the waterhole with splashing muddy water at the savanna

The REDARC BCDC1250D In-vehicle Battery Charger is a 12V 50A In-vehicle DC to DC battery charger. It is the latest variant of the award-winning BCDC Dual range and features REDARC’s Smart Start technology.

Styled with a red line running down its back tells you there’s something different about this dual battery charger. A 50-amp charging output makes it the most powerful in REDARC’s BCDC range.

The BCDC1250D has been developed to provide a higher current output, it features an additional charging stage known as SoftStart which has been engineered to handle more demanding applications.

Featuring a Maximum Power Point Tracking (MPPT) solar regulator, the BCDC1250D will charge from both solar and the alternator simultaneously. And, with built-in ‘Green Power Priority’ it will select solar charging first, meaning less load on the alternator.

Suitable for 12 or 24-volt vehicle systems, the unit will also work with either standard or variable/smart alternators.

It is compatible with all common types of batteries used in automotive and recreational vehicles such as AGM, Gel, standard lead acid, Calcium and LiFeP04.

As a guide, the BCDC1250D is used for battery bank sizes over 200AH. For smaller batteries of 75-200AH REDARC recommends the BCDC1225D.



Contact us to get started on your dream dual battery system!

AT A GLANCE

  •           50amp output makes it the most powerful in REDARC’s BCDC range
  •           Separate DC and solar charging inputs
  •           Maximises the performance and life of your auxiliary battery
  •           Simultaneous DC and solar charging with Green Power Priority
  •           Suits 12V/24V standard and variable voltage/smart alternators
  •           Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries

SPECS

Input ChargeSimultaneous vehicle and solar
Installation TypeIn-cabin or under bonnet
Input (Operating) Voltage9 – 32VDC
Output System Voltage12VDC
Maximum Charging Voltage15.3V
Output Current Rating (Cont.)50A
Input Fuse Rating60A
Output Fuse Rating60A
Standby Current Draw<100mA
Output Power750W
Width (mm)120
Height (mm)37
Length (mm)165
Weight (kg)1
Warranty2 Years

Why purchase from Electric Bug? Here at Electric Bug in Adelaide we are just a phone call or visit away! Unlike some big stores, our salespeople are experts in our products. We are able to assist with any issues or queries you may have and can provide all the advice you need to get started! Not sure what accessories, antennas or mounts will work with your new device? Just ask! We can also assist with repairs and servicing.

Brand

Redarc

Based in South Australia, REDARC has 40 years’ experience in the research, design, development and manufacture of a range of electronic voltage converters and associated products, inverters, power supplies, battery chargers, brake controllers and trailer braking products.In 2015, REDARC acquired Hummingbird Electronics. Hummingbird is renowned for their bespoke product development, unparalleled specialist knowledge and importantly for quality customer service.In 2019, REDARC celebrated its 40-year anniversary and launched REDARC Defence Systems.Under the current ownership, REDARC has grown from humble beginnings to become a world-class, advanced electronics manufacturer, servicing both domestic and international markets
