GME XRS 330C XRS™ Connect

Super Compact Hideaway

Add to Wishlist
Compare
Category:

Description

XRS-330C

XRS™ CONNECT SUPER COMPACT UHF CB RADIO



Get Connected, Get XRS – Bluetooth enabled

XRS™ Connect is an Australian Made radio platform designed to be smart, adaptable and rugged.

Featuring a professional grade speaker microphone complete with a class-leading 2-watt speaker, customisable buttons and a high contrast OLED screen guaranteeing a crystal clear, anti-glare display.

Enabled by Bluetooth® wireless technology, XRS™ Connect is the first of a new generation of connected UHF CB radios with unique features never seen before. They are the first ever UHF CB radios with App control, introducing new features such as creating and sharing scan lists and providing instant access to the entire Australian and New Zealand registered analogue frequency database.

As with many other smart devices, XRS™ Connect products are software upgradable via the XRS™ Connect app, keeping users up-to-date with the latest features and technology.

GME is committed to releasing a minimum of one new upgrade for XRS™ Connect per year to ensure our users always have access to the latest technology available.



Brand

GME

Highlights

  • Bluetooth wireless technology
  • End user software upgradeable via the app
  • Download the XRS Connect App on Google Play or the App Store
  • App compatible with iOS9.0, Android 5.0 and above
  • Easy to configure and customise radio via the app
  • Create and share personalised scan lists – up to 400 frequencies
  • Instant access to over 20,000 receive frequencies
  • XRS Connect speaker microphone with OLED display
  • Customisable buttons
  • 25% faster scan speed at 50 channels per second
  • Memory channel quick select
  • 5 year warranty + 1 additional year for downloading and registering app

Specifications

GENERAL

Compliant Specification
Meets AS/NZS 4365 for radio communications equipment in the UHF citizen and personal radio service.
Frequency Range TX
476.425-477.4125 MHz
Number of Channels
80
Channel Spacing
12.5 kHz
Operation Mode
Simplex or half Duplex with repeater talk around.
Scanning Speed
25 ms per channel (40 channels per second)
Antenna Impedance
50 Ohms nominal
Nominal Battery Voltage
12 volts DC
Operating Voltage Range
10-16 volts DC
Battery Polarity
Negative Earth
Standard Test Voltage
13.8 volts DC
Overvoltage Protection
30 volts DC max. At 18 volts DC the RF power is reduced, and the words ‘Hi DC’ flash.
Reverse Voltage Protection
Diode Crowbar
Overcurrent Protection
In-line 2 amp fuse
Operating Temperature
-10°C to 60°C

TRANSMITTER

RF Output
5 watts
Spurious Emission
< – 70 dBc
Frequency Error
< ± 1.5 kHz
Modulation
FM
Maximum Deviation
< ± 2.5 kHz at + 20 dB limiting
Transmit Frequency Response
+6 dB per octave 300 Hz to 3 kHz +1-3 dB
Demodulated Audio Signal to Noise
> 45 dB unweighted
Current Consumption
1.5 amps with 50 Ohms termination

RECEIVER

Intermediate Frequencies
38.85 MHz, 450 kHz
Sensitivity
– 122 dBm for 12 dB SINAD unweighted
Selectivity
– 6 dB at + 3.5 kHz, ‑ 60 dB at ± 12.5 kHz
Intermodulation Immunity
-72 dB
Blocking Immunity
-98 dB
Spurious Response Immunity
70 dB
Audio Output Power
3 watts average into 4 Ohms
Audio Signal to Noise
> 45 dB unweighted
Current consumption
< 175 mA muted 750 mA Full volume
Conducted Spurious Emission
< – 70 dBm

MECHANICAL SPECIFICATIONS

Dimensions
21 (H) x 100 (L) x 87 (D) mm
Weight
450 grams
Antenna
SO239 panel socket
External Speaker
3.5 mm mono jack
Microphone Port
6 Way telephone style with rubber strain relief

In The Box

  • XRS-330C Super Compact UHF CB radio with Bluetooth Smart Connectivity
  • XRS Connect speaker microphone
  • Microphone clip and radio mounting bracket
  • DC power Lead
  • Screw pack
  • LE040 Mic extension lead
  • AD008 Mic extension adaptor kit
  • Quick start guide
