xrs370c4pg

GME XRS-370C 4WD Pack with GPS

$749.00

XRS-370C4PG 4WD PACK - Includes GPS-Enabled XRS-370C and AE4704B

Out of stock

SKU: XRS-370C4PG Category:

Description

Western Australia – Flooded Outback gravel road with 4WD car crossing the waterhole with splashing muddy water at the savanna

XRS™ CONNECT 4WD PACK

The XRS 4WD pack is the latest addition to the revolutionary range of XRS radios, designed to be smart, adaptable and rugged.

The XRS370 4WD Pack pairs the top-of-the-line XRS-370C Compact UHF CB Radio, with the Heavy Duty AE4704B radome antenna, the perfect solution for those users looking for the ultimate communications setup for their hardcore 4WD.



Simply add on a mounting bracket from our huge range of bullbar brackets, gutter mounts and roof rack mounts to complete your GME UHF kit.

Professional Grade Features and Continuing Improvements

Featuring a professional grade speaker microphone complete with a built-in GPS receiver offering true location awareness without relying on a smartphone to provide GPS location data. The XRS-C4PG microphone offers a class-leading 2-watt speaker, customisable buttons and a high contrast OLED screen guaranteeing a crystal clear, anti-glare display.

Enabled by Bluetooth® wireless technology, XRS™ Connect is the first of a new generation of connected UHF CB radios with unique features never seen before. They are the first ever UHF CB radios with App control, introducing new features such as creating and sharing scan lists and providing instant access to the entire Australian and New Zealand registered analogue frequency database.

As with many other smart devices, XRS™ Connect products are software upgradable via the XRS™ Connect app, keeping users up-to-date with the latest features and technology.

GME is committed to releasing a minimum of one new upgrade for XRS™ Connect per year to ensure our users always have access to the latest technology available.

SPECS

  • 5 Watt Transmission Power
  • Rugged, Die-cast Metal Chassis with Built-In Speaker
  • Bluetooth Wireless Technology – Smartphone Control
  • Water and Dustproof OLED Speaker Microphone
  • Class-leading 2 Watt Front-facing Speaker
  • Built-in GPS Receiver – Location Aware
  • Includes 2.1dBi Medium Duty Radome Antenna
  • XRS Connect – Smartphone Application

TECHNICAL

GENERAL

Compliant Specification
Meets AS/NZS 4365 for radio communications equipment in the UHF citizen and personal radio service.
Frequency Range TX
476.425-477.4125 MHz
Number of Channels
80
Channel Spacing
12.5 kHz
Operation Mode
Simplex or half Duplex with repeater talk around.
Scanning Speed
25 ms per channel (40 channels per second)
Antenna Impedance
50 Ohms nominal
Nominal Battery Voltage
12 volts DC
Operating Voltage Range
10-16 volts DC
Battery Polarity
Negative Earth
Standard Test Voltage
13.8 volts DC
Overvoltage Protection
30 volts DC max. At 18 volts DC the RF power is reduced, and the words ‘Hi DC’ flash.
Reverse Voltage Protection
Diode Crowbar
Overcurrent Protection
In-line 2 amp fuse
Operating Temperature
-10°C to 60°C
Zones
8 (50 channels per zone)
Scan lists
3

TRANSMITTER

RF Output
5 watts
Spurious Emission
< – 70 dBc
Frequency Error
< ± 1.5 kHz
Modulation
FM
Maximum Deviation
< ± 2.5 kHz at + 20 dB limiting
Transmit Frequency Response
+6 dB per octave 300 Hz to 3 kHz +1-3 dB
Demodulated Audio Signal to Noise
> 45 dB unweighted
Current Consumption
1.5 amps with 50 Ohms termination

RECEIVER

Intermediate Frequencies
38.85 MHz, 450 kHz
Sensitivity
– 122 dBm for 12 dB SINAD unweighted
Selectivity
– 6 dB at + 3.5 kHz, ‑ 60 dB at ± 12.5 kHz
Intermodulation Immunity
-72 dB
Blocking Immunity
-98 dB
Spurious Response Immunity
70 dB
Audio Output Power
3 watts average into 4 Ohms
Audio Signal to Noise
> 45 dB unweighted
Current consumption
< 175 mA muted 750 mA Full volume
Conducted Spurious Emission
< – 70 dBm

MECHANICAL SPECIFICATIONS

External Speaker
3.5 mm mono jack

OTHER

Display type
OLED

INCLUDED

  • XRS-370C UHF CB radio with Bluetooth Smart Connectivity
  • Professional-grade OLED Speaker Microphone with GPS (MC668B-M)
  • Heavy Duty UHF CB Radome Antenna (AE4704B)
  • Magnetic Microphone Mounting Bracket (MB207)
  • Shielded Microphone Extension Lead (LE121)
  • Microphone Extension Adaptor Kit (AD008)
  • 12V DC Power Lead (LE09)
  • Mounting Bracket
  • Mounting Hardware
  • Quick Start Guide
