Description

The Icom IC-41PRO – Waterproof Handheld UHF CB for professionals.

This waterproof handheld UHF CB is easy to use with compact rugged construction. It’s an 80 channel radio with in range indicator and duplex operation, providing repeater access. Waterproof and dustproof, the IC-41PRO can handle whatever you throw at it. It is also programmable, meaning it’s ideal for those working in construction or commercial industries. This walkie talkie is available in Black, Red and Hi Vis Orange!

If you require programming, or want to apply for a private frequency, we can help. So give us a call and our commercial services staff can assist with programming, ACMA licence applications, and more!

Why purchase from Electric Bug? Here at Electric Bug in Adelaide we are just a phone call or visit away! Unlike some big stores, our salespeople are experts in our products. Therefore we are able to assist with any issues or queries you may have and can provide all the advice you need to get started! Not sure what accessories, antennas or mounts will work with your new device? Just ask! We can also assist with repairs and servicing.

HIGHLIGHTS

• 80 Channel UHF CB (*)
• Waterproof and dustproof (IP67)
• 5 year warranty on radio
• 18hr typ. operating time with BP280
• Simple operation
• New rotary Channel Selector/Squelch control
• Voice announcement of channel number
• VOX capability with optional headset options
• Scrambler capability built in (**)
• Receive only Channels (**) – up to 35
• Unique repeater scan plus open, group and priority scan
• In-range indicator (ATS)
• Output power 5 Watts (low power 1 Watt)
• Built-in CTCSS/DCS (providing silent stand-by)
• Selective Calling (SELCALL)
• Duplex operation, providing repeater access
• Compact and rugged construction (based on a commercial product)
• Private Channels from 450-520 MHz available for commercial users (dealer programmable), requires FASC72U antenna (frequency between 490-520MHz)
• CS-41PRO User software available for customisation of operation (requires OPC-478UC cable)

INCLUDED

• IC-41PRO Handheld UHF CB Radio
• Antenna
• Belt Clip
• Battery Charger
• Battery Pack
• AC Adaptor

OWNERS MANUAL

IC-41PRO Manual

Brand

iCOM

Specifications

General

• Frequency range 476.4250 MHz to 477.4125 MHz AUS CB
450 MHz to 520 MHz Private/Receive Only
• Number of conventional channels: 128 ch
• Type of emission: W: 16K0F3E (25.0kHz) AUS CB
N: 8K50F3E (12.5kHz) AUS CB
• Antenna impedance: 50 ohms
• Input impedance (MIC): 2.2k ohms
• Output impedance (audio): 8 ohms
• Intermediate frequency: 1st 46.35 MHz, 2nd 450 kHz
• Operating temperature range: – 30o
C to + 60o
C
• Power supply voltage: 7.5 V DC
• Current drain (approx.) Receive stand-by 80 mA
Receive max.audio 300 mA (INT SP)
Transmit Hi (5W) 1.7 A AUS CB
• Dimensions: W 52.2 x H 111.8 x D 30.3mm (with BP-280)
• Weight: 270 grams (with BP-280 and MB-133)

Transmitter

• Rated output power 5 W
• Modulation: Variable reactance frequency modulation
• Maximum permissible deviation ±2.5 kHz (N)
±5.0 kHz (W)
• Frequency error: ±2.5 ppm
• Spurious emissions: 70 dB min
• Adjacent channel power: 60 dB min 69 dB typ. (N)
70 dB min 74 dB typ. (W)
• Audio harmonic distortion: 1.0% typ. @ AF 1 kHz 40 % Deviation (W)
1.5% typ. @ AF 1 kHz 40 % Deviation (N)
• FM Hum and Noise 34 dB min 40 dB typ. (N)
(Without CCITT FILTER) 40 dB min 46 dB typ. (W)
• Limiting characteristic of modulator: 60 % ~ 100 % of max. deviation

Receiver

• Sensitivity: 0.25μV typ. @ 12 dB SINAD
• Audio power output 1.5 W typ. @ 5 % dist. with 8Ω
• Adjacent channel selectivity 40 dB min 56 dB typ.(N)
70 dB min 73 dB typ.(W)
• Spurious response 70 dB min
• Intermodulation 70 dB min 73 dB typ.
• Hum and Noise 34 dB min 43 dB typ. (N)
(without CCITT Filter ) 40 dB min 49 dB typ. (W)
• Squelch sensitivity 0.25μV typ.
