Description
• High Resolution 12/24V monitor kit that offers a clear image and enhanced view when reversing
• The HD7130K also has the added flexibility of connecting up to 2 cameras. (1 camera included)
• Its Heavy Duty construction makes it suitable for trucks, machinery and vehicles
MONITOR
– TFT Panel: New Grade A LCD
– LCD Size: 5-Inch (Diagonal)
– Display Format: 16:9
– Resolution: 1024 x 600
– Brightness: < 500 CD/M2
– Viewing Angles: 70° Left/Right/Up/Down
– Video System: Auto PAL/NTSC Select
– Video Connect: 2 x 4-Pin (Male)
– Compatibility: Standard & High Resolution Camera’s
– Buttons: Touch Sensitive
– Connection Type: Universal Standard 4-Pin Configuration (M)
– Camera Triggers: 2
– Monitor View: Normal/Mirror/Flip/Mirror-Flip Image Select
– Guidelines: Selectable On/Off (Camera 2 Input Only)
– Audio: Camera 2 Input Only
– Main Menu: Brightness/Contrast/Colour/Photosensitive (Dimmer), Language, Default Setting, Volume, RLUD, (Screen Orientation), VCOM (Exposure), Ruler Setting (Guidelines), AccTime, Version
– Operating Temp: -20°C to +70°C
– Power Input: 10-32V DC (Negative Ground)
– Dimensions: 132.2W x 94.3H x 22.45D mm (Excluding bracket & Visor)
– LCD Size: 5-Inch (Diagonal)
– Display Format: 16:9
– Resolution: 1024 x 600
– Brightness: < 500 CD/M2
– Viewing Angles: 70° Left/Right/Up/Down
– Video System: Auto PAL/NTSC Select
– Video Connect: 2 x 4-Pin (Male)
– Compatibility: Standard & High Resolution Camera’s
– Buttons: Touch Sensitive
– Connection Type: Universal Standard 4-Pin Configuration (M)
– Camera Triggers: 2
– Monitor View: Normal/Mirror/Flip/Mirror-Flip Image Select
– Guidelines: Selectable On/Off (Camera 2 Input Only)
– Audio: Camera 2 Input Only
– Main Menu: Brightness/Contrast/Colour/Photosensitive (Dimmer), Language, Default Setting, Volume, RLUD, (Screen Orientation), VCOM (Exposure), Ruler Setting (Guidelines), AccTime, Version
– Operating Temp: -20°C to +70°C
– Power Input: 10-32V DC (Negative Ground)
– Dimensions: 132.2W x 94.3H x 22.45D mm (Excluding bracket & Visor)
CAMERA
12V Heavy Duty Camera
– Sensor: 1/3” IMX225LQR-C
– Diagonal Viewing Angle: 140°
– Horizontal Viewing Angle: 120°
– Signal System: PAL
– Effective Pixels: 1280H x 720V
– Resolution: 720p
– Orientation: Mirror Image
– Night Vision: 18 Infrared LED’s
– Illumination: 0.001 Lux with IR on
– Ingress Protection: IP69K
– Integrated Microphone: Yes
– Operating Temp: -20 to 70° C
– Power Consumption: 3W, 250mA
– Dimensions: 98.3W x 67.7H x 68D mm (including Bracket)
– Connection Type: Universal Standard 4-Pin Female
– Power Supply: 12V DC
– Diagonal Viewing Angle: 140°
– Horizontal Viewing Angle: 120°
– Signal System: PAL
– Effective Pixels: 1280H x 720V
– Resolution: 720p
– Orientation: Mirror Image
– Night Vision: 18 Infrared LED’s
– Illumination: 0.001 Lux with IR on
– Ingress Protection: IP69K
– Integrated Microphone: Yes
– Operating Temp: -20 to 70° C
– Power Consumption: 3W, 250mA
– Dimensions: 98.3W x 67.7H x 68D mm (including Bracket)
– Connection Type: Universal Standard 4-Pin Female
– Power Supply: 12V DC
Included
-Monitor
-CHD10 H/DUTY Camera
-Sun Visor
-U-Bracket
